Description

The 100GE QSFP28 cable assemblies are high performance, cost effective I/O solutions for LAN, HPC and SAN. The high speed cable assemblies meet and exceed 100 Gigabit Ethernet, InfiniBand EDR and temperature requirements for performance and reliability. The cables are compliant with SFF-8436 specifications and provide connectivity between devices using QSFP ports.

 Features

▪ QSFP28 conforms to the Small Form Factor SFF8665

▪ 4-Channel Full-Duplex Active Copper Cable Transceiver

▪ Support data rates : 25.78Gb/s (per channel)

▪ IEEE 802.3 CAUI-4

▪ Copper link length from 5m to 10m

▪ Power Supply :+3.3V

▪ Low crosstalk

▪ I2C based two-wire serial interface for EEPROM signature which can be customized

▪ Operating Temperature: 0~ 70 °C

▪ ROHS Compliant

 Standards Compliance

▪ IEEE 802.3bj

▪ InfiniBand EDR

▪ QSFP28 MSA

▪ RoHS Compliant

 Applications

▪ 100 Gigabit Ethernet

▪ Fiber Channel over Ethernet

▪ Data storage and communication industry

▪ Switch / router / HBA

▪ Enterprise network

▪ SAN

▪ Data Center Network
