Name:ZTE GPON ONT F660 V6.0 (internal antenna)

Product Description

Product Description
Technical items Descriptions
Model F660 6.0
Out Port contains 1GE+3FE+1TEL+1USB+WiFi
WIFI signal 2.4GWiFi
Wireless gain 3db
USB USB2.0
LAN 1*10/100/1000Mbps adaptive Ethernet ports, full/half duplex, RJ45 interface
TEL H248/Sip  Voice protocol
PPPOE support
Firmware English
Dimension/weight 180mm*120mm*35mm/256g
Fiber port 1 GPON interface, ingle-fiber, Downstream rate 2.5Gbps, Upstream rate 1.25Gbps
Wavelength Tx 1310nm, Rx 1490nm
Fiber interface SC/FC-UPC/APC Dual mode/Singal mode
RX sensitivity >-28dBm (1490nm)
DC power 12V 1.5A, external AC-DC power adapter
Button Reset, power,LIGHT
Operation Working temperature: -5- +55℃  working humidity:10-90%(non-condensation)
Storage Storage temperature: -30℃- +60℃ storage humidity: 10-90%(non-condensation)





Feature
1.Plug-and-play: services can be deployed by one click on the NMS, and on-site configuration is not required.
2.Remote diagnosis: Remote fault locating is implemented by the loop-line test of POTS ports, call emulation and PPPoE dialup emulati
3.Link monitoring: E2E link detection is achieved using 802.1ag Ethernet OAM.
4.High speed forwarding: 900 Mbit/s forwarding in the NAT scenario.
5.IPv6 Capability: support IPv6/IPv4 dual stack and DS-Lite.
